We are offering our client an excellent quality range of Steel Flanges. These Steel Flanges are made from very high quality stainless steel raw material which ensures high durability at its user end. These ASME Steel Flanges are available in various designer patterns and designs. Our range of ASME Steel Flanges are available at most reasonable prices.
GOST/ГОСТ 12820-80 FLANGE PN0.6MPA FORGED
Dimensions & Masses of GOST 12820-80 Flange PN0.6MPa
| Давление PN = 0,6 МПа (6 кгс/с м²) | |||||||
| Наименование | D, мм |
D1, мм |
dв, мм |
b, мм |
d, мм |
отв., шт. |
Масса, кг. |
| Фланец плоский ГОСТ 12820-80 (01) 1-15-6 ст.3 (20) | 80 |
55 |
19 |
10 |
11 |
4 |
0,33 |
| Фланец плоский ГОСТ 12820-80 (01) 1-20-6 ст.3 (20) | 90 |
65 |
26 |
12 |
0,53 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-25-6 ст.3 (20) | 100 |
75 |
33 |
12 |
0,64 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-32-6 ст.3 (20) | 120 |
90 |
39 |
13 |
14 |
1,01 |
|
| Фланец плоский ГОСТ 12820-80 (01) 1-40-6 ст.3 (20) | 130 |
100 |
46 |
13 |
1,21 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-50-6 ст.3 (20) | 140 |
110 |
59 |
13 |
1,33 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-65-6 ст.3 (20) | 160 |
130 |
78 |
13 |
1,63 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-80-6 ст.3 (20) | 185 |
150 |
91 |
15 |
18 |
2,44 |
|
| Фланец плоский ГОСТ 12820-80 (01) 1-100-6 ст.3 (20) | 205 |
170 |
110 |
15 |
2,85 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-125-6 ст.3 (20) | 235 |
200 |
135 |
17 |
8 |
3,88 |
|
| Фланец плоский ГОСТ 12820-80 (01) 1-150-6 ст.3 (20) | 260 |
225 |
161 |
17 |
4,39 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-200-6 ст.3 (20) | 315 |
280 |
222 |
19 |
5,89 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-250-6 ст.3 (20) | 370 |
335 |
273 |
20 |
12 |
7,67 |
|
| Фланец плоский ГОСТ 12820-80 (01) 1-300-6 ст.3 (20) | 435 |
395 |
325 |
20 |
22 |
10,28 |
|
| Фланец плоский ГОСТ 12820-80 (01) 1-350-6 ст.3 (20) | 485 |
445 |
377 |
22 |
12,58 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-400-6 ст.3 (20) | 535 |
495 |
426 |
24 |
16 |
15,2 |
|
| Фланец плоский ГОСТ 12820-80 (01) 1-500-6 ст.3 (20) | 640 |
600 |
530 |
25 |
19,72 |
||
| Фланец плоский ГОСТ 12820-80 (01) 1-600-6 ст.3 (20) | 755 |
705 |
630 |
25 |
26 |
20 |
26,24 |
| Фланец плоский ГОСТ 12820-80 (01) 1-800-6 ст.3 (20) | 975 |
920 |
820 |
27 |
30 |
24 |
46,14 |
| Фланец плоский ГОСТ 12820-80 (01) 1-1000-6 ст.3 (20) | 1 175 |
1 120 |
1 020 |
31 |
28 |
64,36 |
|
| Фланец плоский ГОСТ 12820-80 (01) 1-1200-6 ст.3 (20) | 1 400 |
1 340 |
1 220 |
34 |
33 |
32 |
99,03 |
| Проход условный Dy | Py 0,6 МПа (6 кгс/см2) | |||||
| dн | dв | b | Масса, кг | |||
| с соединительным выступом | с выступом | с впадиной | ||||
| 10 | 14 | 15 | 10 | 0,31 | 0,31 | 0,30 |
| 15 | 18 | 19 | 0,33 | 0,33 | 0,32 | |
| 20 | 25 | 26 | 12 | 0,53 | 0,53 | 0,51 |
| 25 | 32 | 33 | 0,64 | 0,64 | 0,62 | |
| 32 | 38 | 39 | 13 | 1,01 | 1,02 | 0,98 |
| 40 | 45 | 46 | 1,21 | 1,19 | 1,16 | |
| 50 | 57 | 59 | 1,33 | 1,30 | 1,27 | |
| 65 | 76 | 78 | 1,63 | 1,60 | 1,55 | |
| 80 | 89 | 91 | 15 | 2,44 | 2,40 | 2,35 |
| 100 | 108 (А) | 110 | 2,85 | 2,81 | 2,72 | |
| 114 (Б) | 116 | 2,73 | 2,66 | 2,60 | ||
| 125 | 133 (А) | 135 | 17 | 3,88 | 3,84 | 3,70 |
| 140 (Б) | 142 | 3,68 | 3,59 | 3,50 | ||
| 150 | 152 (А) | 154 | 4,63 | 4,65 | 4,43 | |
| 159 (Б) | 161 | 4,39 | 4,36 | 4,19 | ||
| 168 (В) | 170 | 4,09 | 3,98 | 3,89 | ||
| (175) | 194 | 196 | 19 | 5,36 | 5,33 | 5,14 |
| 200 | 219 | 222 | 5,89 | 5,86 | 5,65 | |
| (225) | 245 | 245 | 6,60 | 6,60 | 6,29 | |
| 250 | 273 | 273 | 20 | 7,67 | 7,64 | 7,34 |
| 300 | 325 | 325 | 10,28 | 10,18 | 9,74 | |
| 350 | 377 | 377 | 22 | 12,58 | 12,45 | 12,00 |
| 400 | 426 | 426 | 24 | 15,20 | 15,07 | 14,53 |
| (450) | 480 | 480 | 17,25 | 17,04 | 16,52 | |
| 500 | 530 | 530 | 25 | 19,72 | 19,57 | 18,86 |
| 600 | 630 | 630 | 26,24 | 25,91 | 24,96 | |
| (700) | 720 | 720 | 27 | 36,68 | 36,27 | 35,28 |
| 800 | 820 | 820 | 46,14 | 45,66 | 43,65 | |
| (900) | 920 | 920 | 29 | 55,10 | - | - |
| 1000 | 1020 | 1020 | 31 | 64,36 | ||
| 1200 | 1220 | 1220 | 34 | 99,03 | ||
| 1400 | 1420 | 1420 | 43 | 161,45 | ||
| 1600 | 1620 | 1620 | 48 | 203,05 | ||
